Research Inverted Biological Microscope

The Bioserver Standard research inverted biological microscope series is based on the ergonomic design concept, Adopting the idea of modular structure design

Inquire Now Next Product

Product Description:

The Bioserver Standard research inverted biological microscope series is based on the ergonomic design concept, Adopting the idea of modular structure design, Equipped with an excellent infinity chromatic aberration correction optical system, With high-definition brightfield, darkfield, fluorescence, phase contrast, DIC, polarized light and other observation methods, It can provide a relatively complete solution for life science research such as biological cells, bacteria and living tissue culture.

Technical Specifications of Research Inverted Biological Microscope:

Specifications	Paraeter
Model Type	Research Inverted Biological Microscope
Optical System	Infinity Chromatic Aberration Correction Optical System
Way of Observation	Brightfield, Darkfield, DIC, Polarized Light, Fluorescence
Widefield Transmitted Illumination	100W halogen lamp（Standard）
Widefield Transmitted Illumination	5000K LED（Optional）
Fluorescent Lighting	100W Full Spectrum Mercury Lamp
Observation Tube	30° Hinged three-way lens barrel
	Interpupillary distance adjustment range: 47-75 mm
	Compatible with C-mount CCD
Eyepiece	WFX10-25mm, Φ30
Output Port	3
Focusing Unit	Manual: ±7.5mm, Precision 1um（Standard）
Focusing Unit	Intelligent automatic: ±7.5mm, precision0.5um（Optional）
Nosepiece	manual: 6-hole RMS standard interface（Standard）
Nosepiece	electric: 6-hole RMS standard interface（Optional）
Objective Lens （ Parfocal Length 45mm）	4X NA 0.13
	10X NA 0.3
	20X NA 0.45
	40X NA 0.65
	60X NA 0.85
Stage	Manual mechanical platform: （Standard） Stage size 300(X) x 200mm(Y) Stroke100(X) x 65mm(Y)
Stage	Electromechanical Platform: （Optional） Stage size 300(X) x 200mm(Y) Repeatability 1um
Epi-Fluorescence Accessories	Epi-fluorescence filter cube carousel
	Filter block with noise cancellation mechanism
	Up to five epi-fluorescence blocks can be configured
Dimensions (WxLxH)	337 x 846 x 701 mm
Weight	42.5 KG
Power Supply	90-250V, Wide voltage Transformer: Alternating current 220Vor110V

Why Choose Us?

Advanced technology research and development capabilities

The company has continuously introduced outstanding talents at home and abroad, and has a research and development team composed of advanced technical talents such as doctoral and master students and senior professional engineers. Independent research and development, with a total of more than 40 patents for technical inventions and utility models related to optical lenses, lenses and instruments.

With strong R&D capabilities, advanced production equipment and strict quality control system, our lens series has expanded to a wide range of industrial-grade products, covering 1/7.5", 1/4", 1/3", 1/1.8", 2/3” to 1.2” and even larger, there are corresponding solutions to support.

The company's lens and lens products cover the fields of security, machine vision, medical, automotive, sights, smart home and sports cameras. According to customer needs, we can provide ODM services and exclusive customized research and development.
Excellent manufacturing capacity

HR Optoelectronics always adheres to high-standard product quality requirements to provide customers with comprehensive solutions for optical products, pays attention to product quality, and is fully equipped with precision testing instruments and high-end production equipment. Lens, lens and instrument design, research and development, processing, and assembly have a complete production chain and sufficient production capacity, and each link is checked layer by layer.

The imported new Cologne sputtering coating machine is used, which can effectively improve the accuracy of the lens and the uniformity of the transmittance of the film layer; on the detection instrument, the eccentricity detection, surface detection, and coating curve detection are all imported or domestically produced. , to ensure the validity of inspection data and product quality and product yield, thereby improving production efficiency. The complete facilities and the complete personnel provide a strong guarantee for our manufacturing.
Strict inspection process

The company has passed the international quality system certification ISO 9001:2015 and the automotive industry quality management system certification IATF 16949, and has established a rigorous, complete and high-standard quality control system. From procurement to production to after-sales quality control, there is a clear and definite standard system. The company follows the concept of customer orientation and strict process control, and runs quality control procedures throughout the entire life cycle of products to ensure that from raw materials to after-sales service. quality. The company's internal management takes 5S as the standard, and the quality control of product production takes 6sigma as the goal, striving to win the support of customers with the most stable quality.
Perfect supporting services

Our departments have a clear division of labor, production and office work are strictly implemented according to 5S standard. Have perfect pre-sales and after-sales service. With advanced technology R&D capability, high-quality manufacturing capability and strict inspection process, a strong manufacturing, quality control and operation service system has been built, which provides a strong guarantee for the sustained and high-speed development of enterprises.
